CP2E-N20DR-D

CP2E-N20DR-D
CP2E-N20DR-D - Image 2
CP2E-N20DR-D - Image 3
SKU 64984b81c813 Category Tag

Additional information

Part #:

CP2E-N20DR-D
Manufacturer:

Omron
Description:

Omron CP2E Series PLC CPU for Use with CP2E Series, Relay Output, 12-Input, Digital Input
Ask for quote

Product details:

Find similar products by selecting one or more attributes.
Select all
Attribute
Value
Brand Omron
Manufacturer Series CP2E
Number of Inputs 12
Output Type Relay
For Use With CP2E Series
Input Type Digital
Number of Digital Inputs 12
Voltage Category 24 V dc
Number of Outputs 8
Network Type Ethernet
Number of Digital Outputs 8
Interface RS-485
Battery Backup Yes
Memory 16000 Words
Programming Interface Ethernet
Number of Communication Ports 1
Programming Language Used Ladder Diagram
Mounting Type Panel Mount
Width 80mm
Length 86mm
Depth 110mm
Program Capacity 20000 Steps
Display Included Yes
Communication Port Type Ethernet TCP/IP
Dimensions 86 x 80 x 110 mm
Minimum Operating Temperature -20°C
Maximum Operating Temperature +60°C
Select all

Brand

Omron

Manufacturer Series

CP2E

Number of Inputs

12

Output Type

Relay

For Use With

CP2E Series

Input Type

Digital

Number of Digital Inputs

12

Voltage Category

24 V dc

Number of Outputs

8

Network Type

Ethernet

Number of Digital Outputs

8

Interface

RS-485

Battery Backup

Yes

Memory

16000 Words

Programming Interface

Ethernet

Number of Communication Ports

1

Programming Language Used

Ladder Diagram

Mounting Type

Panel Mount

Width

80mm

Length

86mm

Depth

110mm

Program Capacity

20000 Steps

Display Included

Yes

Communication Port Type

Ethernet TCP/IP

Dimensions

86 x 80 x 110 mm

Minimum Operating Temperature

-20°C

Maximum Operating Temperature

+60°C

Omron CP2E Series PLC CPU, For Use With CP2E Series, 24V DC Voltage Category – CP2E-N20DR-D

This PLC CPU is intended to improve industrial automation processes by offering a robust control solution. Its efficient management of inputs and outputs facilitates seamless integration across various systems. This product is relevant for electronics and automation professionals, providing advanced programming options and consistent performance in various environments.

Features & Benefits

• Supports up to 12 digital inputs for flexible control
• Eight relay outputs enable efficient switching
• Ethernet TCP/IP communication allows for remote monitoring
• Ladder diagram programming ensures user-friendly operation
• Built-in battery backup maintains data integrity during power loss

Applications

• Used in automated manufacturing line controls
• Ideal for building management systems that oversee HVAC
• Employed in packaging machines for precise functions
• Integrates with sensors and devices for data acquisition
• Utilised in control panels for streamlined industrial processes

What programming language is supported for developing applications?

Ladder diagram programming is utilised, which is straightforward for users familiar with automation systems.

How can I monitor and control processes remotely?

The device includes Ethernet TCP/IP connectivity, enabling remote access and control via networked systems.

What should I do if I encounter power loss during operation?

The integrated battery backup will retain data integrity, preventing loss of critical information during outages.

Can this product be integrated with other automation devices?

Yes, it supports various digital input and output modules for flexible integration within comprehensive automation systems.
